This feature is available since v5.1.0.
- how to render custom form layout
- how to render UI elements based on user’s permissions
- how to use form data to render custom UI elements
This guide will help you to implement a custom form layout for your Headless CMS content models. By default, our Headless CMS allows you to organize content model fields in a grid layout. That is fine for a basic UI, with several fields. However, as your content model grows, you may need to organize the UI to be more visually appealing and easier to navigate for your content editors.
Custom form layouts will also come in handy if you need to show or hide certain elements of the form based on content editor’s permissions, or even render additional UI like helper text, links, images, etc.
There’s only one plugin you need to implement to create a custom form layout: CmsContentFormRendererPlugin.
Plugins of this type require a
modelId (to match the model in your Headless CMS), and a
render function which returns a React element which will be rendered instead of the default grid based layout.
The plugin demonstrated above renders a content form for
pizza content model.
fields object contains key-value pairs of content model fields, with key being the
fieldId (defined in the content model editor), and value being a React element rendered using the appropriate field renderer. All you need to do is place those field elements in your new layout.
If you want to render UI based on user’s permissions, you’ll need to use security hook. In this example, we’re creating a more elaborate layout for our form, using the
Here’s what a default layout looks like:
Once we import the plugin and register it in our
admin app, we get our custom layout:
You can see the
Recipe tab is hidden. That’s because we don’t have the necessary permission to view it.
Using form data you can also render other UI elements, or even show/hide fields depending on the value of some other field. In the following example, we show a warning if the price is less than
20 and number of ingredients is greater than
Using this approach, you can add a nice touch to your UI and guide the content editor with additional logic, validate the input, and add other helpful elements which would otherwise be really difficult to define on the content model itself:
